Bioconductor toolkit for single-cell RNA velocity

class: center, middle, inverse, title-slide

# Bioconductor toolkit for single-cell RNA velocity <img src="img/velociraptor_sticker.png" height="200px" style="vertical-align:bottom;float:right">
## Bioconductor Conference 2021
### <a href="https://kevinrue.github.io">Kevin Rue-Albrecht</a>, <a href="https://csoneson.github.io">Charlotte Soneson</a>, <a href="https://github.com/mbstadler">Michael Stadler</a>, <a href="https://github.com/LTLA">Aaron Lun</a>
### 2021-08-06 (updated: 2021-07-21)

---

layout: true

<div class="my-footer">
Kevin Rue-Albrecht
&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;&emsp;
velociraptor
</div>

---

# RNA velocity predicts the future state of cells

.right[
.small-p[
RNA velocity field describes fate decisions of major neural lineages in the hippocampus.
<a name=cite-lamanno2018></a>([La Manno, et al., 2018](https://doi.org/10.1038/s41586-018-0414-6))
]
]

---

# RNA velocity from spliced and unspliced mRNAs

.right[
.small-p[
Balance between unspliced and spliced mRNAs is predictive of cellular state progression.
([La Manno, et al., 2018](https://doi.org/10.1038/s41586-018-0414-6))
]
]

---

# scVelo

* Python package
  + [Read the Docs](https://scvelo.readthedocs.io/).

* Estimates RNA velocity from estimates of gene-wise spliced and unspliced abundances.

* Steady-state (deterministic), stochastic, dynamic models.
  + [Read the Docs](https://scvelo.readthedocs.io/about/#rna-velocity-models)

* Uses the `AnnData` class for internal data representation
 + [Read the Docs](https://anndata.readthedocs.io/en/latest/)

* Not straightforward to integrate in an R/Bioconductor-based workflow.

.right[
.small-p[
Generalizing RNA velocity to transient cell states through dynamical modeling
<a name=cite-bergen2020></a>([Bergen, et al., 2020](https://www.ncbi.nlm.nih.gov/pubmed/32747759))
]
]

---

# The Bioconductor factor

![](img/distracted-analyst.jpg)

---

# <img src="img/velociraptor_sticker.png" height="70px" style="vertical-align:bottom"> is a Bioconductor-friendly wrapper of scVelo

<img src="img/bioconductor_sticker.png" height="30px" style="vertical-align:bottom"> *[velociraptor](https://bioconductor.org/packages/3.14/velociraptor)*
uses
<img src="img/bioconductor_sticker.png" height="30px" style="vertical-align:bottom"> *[basilisk](https://bioconductor.org/packages/3.14/basilisk)*
to run [scVelo](https://pypi.org/project/scvelo/)
in a `BasiliskEnvironment`
(i.e., a <img src="img/conda.png" height="30px" style="vertical-align:bottom"> [Conda](https://docs.conda.io/en/latest/) environment).

```r
setMethod("scvelo", "SummarizedExperiment", function(x, ...,
 assay.X="counts", assay.spliced="spliced", assay.unspliced="unspliced")
{
 ...
 output <- basiliskRun(env = velo.env, fun = .run_scvelo,
 X = X, spliced = spliced, unspliced = unspliced,
 use.theirs = use.theirs, mode = mode,
 scvelo.params = scvelo.params,
 dimred = dimred)
 ...
}
```

`velociraptor::scvelo()` returns a `SingleCellExperiment` object containing the output of the velocity calculations.

---

# Input and data representation

* The input to [scVelo](https://pypi.org/project/scvelo/) is two gene-by-cell count matrices, tabulating the UMI count for spliced and unspliced variants of each gene.
* Several tools exist to estimate these counts from the raw reads <a name=cite-soneson2021></a>([Soneson, et al., 2021](https://www.ncbi.nlm.nih.gov/pubmed/33428615)).
* Count matrices are stored as assays in a `SummarizedExperiment` object.
* The <img src="img/bioconductor_sticker.png" height="30px" style="vertical-align:bottom"> *[zellkonverter](https://bioconductor.org/packages/3.14/zellkonverter)* package takes care of conversion between the `AnnData` and `SingleCellExperiment` formats.

.small-code[

```r
hermann
```

```
## class: SingleCellExperiment
## dim: 54448 1711
## metadata(0):
## assays(3): spliced unspliced logcounts
## rownames(54448): ENSMUSG00000102693.1 ENSMUSG00000064842.1 ...
##   ENSMUSG00000064369.1 ENSMUSG00000064372.1
## rowData names(0):
## colnames(1711): TGACAACAGGACAGAA TTGGAACAGGCGTACA ... TCGCGTTCAAGAGTCG
##   CACCTTGCAGATCGGA
## colData names(2): celltype sizeFactor
## reducedDimNames(2): PCA TSNE
## mainExpName: NULL
## altExpNames(0):
```
]

---

# Running velociraptor::scvelo()

Use gene selection, normalization and dimension reduction from [scVelo](https://pypi.org/project/scvelo/), or customize each step in for full compatibility with the rest of the workflow.

.small-code[

```r
hermann_velo <- velociraptor::scvelo(hermann, subset.row = top.hvgs, assay.X = "spliced", use.dimred = "PCA")
hermann_velo
```

```
## class: SingleCellExperiment
## dim: 2000 1711
## metadata(4): neighbors velocity_params velocity_graph
##   velocity_graph_neg
## assays(6): X spliced ... Mu velocity
## rownames(2000): ENSMUSG00000038015.6 ENSMUSG00000022501.6 ...
##   ENSMUSG00000115935.1 ENSMUSG00000029725.10
## rowData names(3): velocity_gamma velocity_r2 velocity_genes
## colnames(1711): TGACAACAGGACAGAA TTGGAACAGGCGTACA ... TCGCGTTCAAGAGTCG
##   CACCTTGCAGATCGGA
## colData names(7): velocity_self_transition root_cells ...
##   velocity_confidence velocity_confidence_transition
## reducedDimNames(1): X_pca
## mainExpName: NULL
## altExpNames(0):
```

```r
reducedDim(hermann_velo, "TSNE") <- reducedDim(hermann, "TSNE")
hermann_velo$celltype <- hermann$celltype
```
]

---

# Project velocities onto low-dimensional embedding

```r
embedded <- embedVelocity(reducedDim(hermann, "TSNE"), hermann_velo)
grid.df <- gridVectors(reducedDim(hermann, "TSNE"), embedded)

plotTSNE(hermann, colour_by="celltype") +
    geom_segment(data = grid.df, mapping = aes(x = start.1, y = start.2,
        xend = end.1, yend = end.2), arrow = arrow(length = unit(0.05, "inches")))
```

---

# Gene-wise visualizations

```r
plotVelocity(hermann_velo, c("ENSMUSG00000032601.13"), use.dimred = "TSNE",
             color_by = "celltype")
```

---

# Stream lines

```r
plotVelocityStream(hermann_velo, embedded, use.dimred = "TSNE",
  color.streamlines = TRUE, color_by = "velocity_pseudotime")
```

---

# Processing a dataset for RNA velocity analysis

* The Hermann spermatogenesis data set used in these slides is available from the <img src="img/bioconductor_sticker.png" height="30px" style="vertical-align:bottom"> *[scRNAseq](https://bioconductor.org/packages/3.14/scRNAseq)* package.
* The script detailing the pre-processing is available [here](https://github.com/LTLA/scRNAseq/blob/master/inst/scripts/2.4.0/make-hermann-spermatogenesis-data.Rmd) 1
* The source code for this presentation is available [here](https://github.com/kevinrue/velociraptor_talk_bioc2021) 2

.center[
<img src="img/scrnaseq-github.png" height="300px">
]

.small-p[
1 Long URL: <https://github.com/LTLA/scRNAseq/blob/master/inst/scripts/2.4.0/make-hermann-spermatogenesis-data.Rmd>

2 Long URL: <https://github.com/kevinrue/velociraptor_talk_bioc2021>
]

---

# References

.small-p[
<a name=bib-bergen2020></a>[Bergen, V. et al.](#cite-bergen2020)
(2020). "Generalizing RNA velocity to transient cell states through
dynamical modeling". In: _Nat Biotechnol_ 38.12, pp. 1408-1414. ISSN:
1546-1696 (Electronic) 1087-0156 (Linking). DOI:
[10.1038/s41587-020-0591-3](https://doi.org/10.1038%2Fs41587-020-0591-3).
URL:
[https://www.ncbi.nlm.nih.gov/pubmed/32747759](https://www.ncbi.nlm.nih.gov/pubmed/32747759).

<a name=bib-orchestrating2015></a>[Huber, W. et
al.](#cite-orchestrating2015) (2015). "Orchestrating high-throughput
genomic analysis with Bioconductor". In: _Nat Methods_ 12.2, pp.
115-21. ISSN: 1548-7105 (Electronic) 1548-7091 (Linking). DOI:
[10.1038/nmeth.3252](https://doi.org/10.1038%2Fnmeth.3252). URL:
[https://www.ncbi.nlm.nih.gov/pubmed/25633503](https://www.ncbi.nlm.nih.gov/pubmed/25633503).

<a name=bib-lamanno2018></a>[La Manno, G. et al.](#cite-lamanno2018)
(2018). "RNA velocity of single cells". In: _Nature_ 560.7719, pp.
494-498. DOI:
[10.1038/s41586-018-0414-6](https://doi.org/10.1038%2Fs41586-018-0414-6).
URL:
[https://doi.org/10.1038/s41586-018-0414-6](https://doi.org/10.1038/s41586-018-0414-6).

<a name=bib-soneson2021></a>[Soneson, C. et al.](#cite-soneson2021)
(2021). "Preprocessing choices affect RNA velocity results for droplet
scRNA-seq data". In: _PLoS Comput Biol_ 17.1, p. e1008585. ISSN:
1553-7358 (Electronic) 1553-734X (Linking). DOI:
[10.1371/journal.pcbi.1008585](https://doi.org/10.1371%2Fjournal.pcbi.1008585).
URL:
[https://www.ncbi.nlm.nih.gov/pubmed/33428615](https://www.ncbi.nlm.nih.gov/pubmed/33428615).
]

.center[
<img src="img/bioconductor_sticker.png" height="300px">
<img src="img/velociraptor_sticker.png" height="300px">
]
